| Tehniskie dati |
| Motor jauda (230 V - 50 Hz) 550W - 0,7CV |
| Gabarītizmēri (GxPxA) 350 x 350 x 800 mm |
| Rotācijas ātrums 2800 T / min |
| Patrona 3 - 13 mm |
| Kalta diametrs 15,9 mm |
| Kalti 6-12 mm |
| Izmērs galds 180 x 157 mm |
| Izmērs vadotnes 180 x 50 mm |
| Pamatnes izmērs 320 x 270 mm |
| Attālums no atdures līdz kaltam 70 mm |
| Vadotnes gājiens 120 mm |
| Galda pārvietosana no vienas puses uz otru 170 mm |
| Maks. urbšanas dziļums 70 mm |
| (Maks. ar kaltu 12mm) |
| Neto svars 42 kg |
| Iepakojuma lielums (GxPxA) 670 x 450 x 340 mm |
| Bruto svars 46 kg |
| • Base, column and mortising head cast iron . |
| • Column with head sliding on dovetail. |
| • Gas strut for controlling movement lowering and raising of the head. |
| • Extra long lever . |
| • Induction motor , tough and quiet. |
| • Stock removal on side dovetail facilities displacements 1 large crank . |
| • Adjustment dial for the longitudinal turning on tail dove . |
| • Roughing side stop . |
| • Depth stop adjustable slotting . |
| • Horizontal presser for holding the piece of wood shaft with a crank. |
| • Base breakthrough for fixing the machine on a workbench. |
| * The machine comes with storage cupboard, the vertical clamps the abutment length , 2 locks chisel 8 and 10 mm, socket 15.9 , keys and instructions. |
