| Technical lata | |
| Weight | 1380/1500/1770kg |
| Pressured air consumption | 50/300l/min |
| Machine dimensions (L/W/H) | 1525×1910×2010/1715×1910×2010/1915×1910×2010mm |
| Desk lifting motor power | -kW |
| Diameter of exhaust opening | 2 × 150/2 × 180mm |
| Air suction speed | 20m/s |
| Voltage / frequency | 3/N/PE 400V/50HzV / Hz |
| operating pressure | 5,5bar |
| Work width | 910/1100/1300mm |
| Maximum workpiece height | 3-160mm |
| Max. operating width | 910/1100/1300mm |
| Min. - Max. workpiece height | 3-160mm |
| Feed belt speed | 4,5/9m/min |
| Grinding belt width | 930/1120/1320mm |
| Grinding roller diameter | 160-200mm |
| Grinding belt speed | 18,5m/min |
| Input of grinding belt motor | 11kW |
| Input of feeding belt motor | 0,58/0,75kW |
