| Technical lata | |
| Weight | 680/1840/2197kg |
| Pressured air consumption | 50/300l/min |
| Machine dimensions (L/W/H) | 1400×1220×1800/1400×1520×1800/1400×1670 × 1800 mm |
| Desk lifting motor power | 0,18 kW |
| Diameter of exhaust opening | 150 mm |
| Air suction speed | 20 m/s |
| Voltage / frequency | 3/N/PE 400V/50HzV / Hz |
| Work width | 650/950/110 0mm |
| Maximum workpiece height | 3-160 mm |
| Max. operating width | 630/930/1100 mm |
| Min. - Max. workpiece height | 3-160 mm |
| Feed belt speed | 4,5/9 m/min |
| Grinding belt width | 650/950/1120 mm |
| Grinding roller diameter | 120 mm |
| Grinding belt speed | 18 m/min |
| Input of grinding belt motor | 5,5/7,5/11 kW |
| Two-speed feeding belt motor | 0,43/0,3 kW |
