TECHNICAL DETAILS
| The diameter of the main saw blade | ⌀ 300 mm |
| Max. height sawing | 75 mm |
| Max. sawing width | 2500 mm |
| Min. Width sawing | 220 mm |
| Max. length sawing | 2500 mm |
| Main engine power | 2 x 4 kW |
| The rotational speed of the main spindle | 3500, 4500, 6000 rpm |
| The diameter of the tip of the main spindle | ⌀ 30 mm |
| The diameter of the saw blade spindle undercut | ⌀ 120 - 130 mm |
| Motor spindle undercut | 2 x 0,75 kW |
| The rotational speed of the spindle undercut | 8300 obr./min. |
| The diameter of the tip of the spindle undercut | ⌀ 20 mm |
| Feeding motor power bracket | 0,37 kW |
| Connection diameter suction top | ⌀ 2 x ⌀ 60 mm |
| The demand of air (in the upper extraction) | 2 x 360 m3/h |
| The demand of air (in the lower extraction) | 2 x 900 m3/h |
| Weight | 1100 kg |
